REM — Rod-shaped cells colonising an iron(III)-oxide (ferrihydrite) coating on a silicon wafer after 11 days with electron donor. Aufnahme auf Artebene (Geobacter sulfurreducens). Adapted from Newsome L et al. (2018), FEMS Microbiol Ecol 94(8):fiy104, Fig. 1B. Quelle · CC BY 4.0 · Cropped to panel B from the figure embedded in the article PDF; converted to WebP

Electrogen · Bidirectional EET · DIET partner donor

Geobacter sulfurreducens PCA

Thermodesulfobacteriota · Desulfuromonadia · Geobacteraceae

ElektroaktivEET bidirectionalTypstammBSL-1Datensatz: Comprehensive
  • Model organism
  • Anode respiring
  • Metal reducer
  • Tier 1
  • DIET donor
Bidirectional
Elektronentransfer
elektroaktiv
30°C
Optimale Temperatur
wächst bei 25–35 °C
6,8
Optimaler pH-Wert
wächst bei pH 6–7,5
4A/m²
Max. Stromdichte
Bereich 1–7,6

01 · Identität

Identität

Wo dieser Organismus im Stammbaum des Lebens steht, wie man ihn bezieht und wie eine Zelle aussieht.

Abstammungslinie

  1. DomäneBacteria
  2. ›PhylumThermodesulfobacteriota
  3. ›KlasseDesulfuromonadia
  4. ›OrdnungGeobacterales
  5. ›FamilieGeobacteraceae
  6. ›GattungGeobacter
  7. ›ArtGeobacter sulfurreducens PCA

Früher klassifiziert als Deltaproteobacteria.

Stammsammlungen & Zugangsnummern

DSMZ
DSM 12127
ATCC
ATCC 51573
NCBI-Taxon
243231
Genom
GCF_000007985.2
Status
Typstamm

Isolierung

Isoliert aus Potomac River sediment, Maryland, USA von Caccavo F. et al. (1994).

Caccavo F, et al. (1994). Geobacter sulfurreducens sp. nov. PubMed

Genom

3,81Mb
Genomgröße
60,9%
GC-Gehalt
Complete
Assemblierungsstufe
1
Contigs

Zellmorphologie

Rod, Gram-negative (diderm)

Länge 2,5 (1,5–4) µm · Breite 0,5 (0,4–0,7) µm

  • Beweglich: nein
  • Pili: ja
  • Kapsel: nein
  • S-Layer: nein
  • Vesikel der äußeren Membran: nein
  • Sporenbildend: nein

02 · Elektronentransfer

Elektronentransfer

Wie Elektronen die Zellhülle überwinden – die Eigenschaft, die einen Mikroorganismus in einem elektrochemischen System nützlich macht.

ElektroaktivEET bidirectional
ZELLEELEKTRODEAUSSENMEMBRAN-CYTOCHROMEOmcBOmcCOmcSOmcZe⁻e⁻NANODRAHT · OMCS CYTOCHROME FILAMENTe⁻e⁻DIET → M. harundinaceae⁻e⁻
Elektronen fließen in beide Richtungen

Mechanismen

  • Außenmembran-Cytochrome: ja
  • Leitfähige Pili / Nanodrähte: ja
  • Endogene Shuttles: nein
  • Exogene Shuttles: nein

Leitfähigkeit der Nanodrähte 0,028 (0,001–0,5) S/cm

OmcS filament intrinsic conductivity ~28 mS/cm; values vary widely with measurement method (network vs single-filament). See Wang 2019, Yalcin 2020.

Redoxleiter

H⁺/H₂Acetat/CO₂-0,5-0,4-0,3-0,2-0,10,00,10,20,31234
■ Cytochrom · ○ ShuttleE°′ (V vs. SHE)
  1. 1OmcZ -0,22 V · Extracellular · 8 Hämgruppen
  2. 2OmcS -0,212 V · Nanowire filament · 6 Hämgruppen
  3. 3OmcB -0,19 V · Outer membrane · 12 Hämgruppen
  4. 4PpcA -0,15 V · Periplasm · 3 Hämgruppen

Cytochrome (14)

NameLokalisationHämgruppenE°′VStruktur
CbcLInner membrane9——

Required for low-potential (≤−0.1 V) electron transfer.

ImcHInner membrane6——

Inner-membrane cytochrome required for high-potential acceptors.

OmaBOuter membrane———

Component of the OmaB-OmbB porin-cytochrome complex.

OmaCOuter membrane———

Component of the OmaC-OmbC porin-cytochrome complex.

OmbBOuter membrane———

β-barrel porin partner of OmaB.

OmbCOuter membrane———

β-barrel porin partner of OmaC.

OmcBOuter membrane12-0,19—

Outer-membrane dodecaheme; required for Fe(III) citrate reduction.

OmcCOuter membrane12——

Paralog of OmcB; less essential phenotypically.

OmcENanowire filament4——

Tetraheme nanowire identified by cryo-EM (Wang 2022).

OmcSNanowire filament6-0,212PDB 6EF8EMDB EMD-9046

Forms the canonical conductive nanowire filament (Wang 2019).

OmcZExtracellular8-0,22PDB 7TFS

Octaheme; high-current-density biofilm filament (Yalcin 2020).

PpcAPeriplasm3-0,15—

Periplasmic triheme; central to Fe(III) and U(VI) reduction.

PpcBPeriplasm3——

PpcA paralog.

PpcDPeriplasm3——

PpcA paralog.

Direkter Transfer – Details

Completeness
Mapped
Nanowire length
5 (1–20) µm

Vermittelter Transfer – Details

Completeness
Mapped

03 · Wachstumsbereich

Wachstumsbereich

Die Bedingungen, die dieser Organismus toleriert, wovon er sich ernährt und was er veratmet – das Betriebsfenster für einen Reaktor.

MesophileObligate anaerobeChemoorganoheterotroph
Temperature30 (25–35) °C
0100 °C
pH6,8 (6–7,5)
014
Doubling time8 (6–12) h
020 h

Energiestoffwechsel

Elektronendonatoren

  • Acetate
  • H2
  • Formate

Elektronenakzeptoren

  • Fe(III)
  • Mn(IV)
  • Fumarate
  • Anode
  • S0
  • U(VI)

Kohlenstoffquellen

  • Acetate
  • Hydrogen
  • Formate
  • Lactate
  • Pyruvate
  • Respiratorisch: ja
  • Fermentativ: nein

Stoffwechsel – Details

ATP synthase type
Proton dependent
Energy conservation mechanism
Oxidative phosphorylation

Wachstumskinetik

Ks (Substrat)2,9 mM
05 mM

From 3 DB row(s) across 2 paper(s); source units: mM. Includes engineered/variant strings: Geobacter sulfurreducens. Full provenance: services/ml-engine/data/kinetics-extracted/per-strain-aggregated.json.

Lag phase
1 h

04 · Wachstums- & Elektronentransferkinetik

Wachstums- & Elektronentransferkinetik

Wie schnell dieser Organismus wächst und wie er Elektronen mit einer Elektrode austauscht (er gilt als zu beidem fähig), wie das Korpus es berichtet, und was diese Konstanten ergeben, wenn man sie rechnet.

Kinetische Belege

Wachstums- und Stromkonstanten teilen eine Substratbasis: Acetat.

ParameterWertStreuungnQuelle
Aus dem Korpus · Median und 10–90-%-Streuung
Max. spezifische Wachstumsrate μmaxaus der Verdopplungszeit, ln 2 / t_d0,0715 h⁻¹—1 · 1 PublikationDB-Zeilen
median of 1 measurement(s) from 1 paper(s); organisms: G. sulfurreducens PCA; substrate: acetate; 1 of 1 derived from doubling time as ln 2 / t_d (a realised growth rate; equals mu_max only when S >> Ks)
Max. Stromdichte jmaxaus dem Substrataufnahmefluss bei 100 % Coulomb-Effizienz: eine Obergrenze7,93 A/m²6,9–10,165 · 1 PublikationDB-Zeilen
median of 5 measurement(s) from 1 paper(s); organisms: Geobacter spp., Geobacter spp. enrichment biofilm; substrate: acetate; 13 duplicate row(s) collapsed; 5 of 5 derived from substrate uptake flux × electrons per mole × F, the current at 100 % coulombic efficiency (an upper bound on j_max)
Halbsättigung des Stroms Ks (Strom)60,22 mg/L19,01–171,27 · 3 PublikationenDB-Zeilen
median of 7 measurement(s) from 3 paper(s); apparent half-saturation of biofilm current (Michaelis-Menten Km), not Monod growth Ks; organisms: Geobacter spp., Geobacter spp. enrichment biofilm, Geobacter sulfurreducens; substrate: acetate; 15 duplicate row(s) collapsed
Prior auf Gattungsebene · Median und kuratierter Bereich
Halbsättigungskonstante Ks80 mg/L20–2004 Publikationen, kuratiertGattungs-Prior · 3 Quellen
Acetate Ks from acetate-limited chemostat (Esteve-Núñez 2005).; range = curated low/high, not percentiles
Biomasseausbeute Y0,07 g/g0,04–0,14 Publikationen, kuratiertGattungs-Prior · 3 Quellen
Biomass yield on acetate (g dry cells / g acetate).; range = curated low/high, not percentiles
Noch keine Belege
Absterbekoeffizient kdWeder im Korpus noch im Gattungs-Priorfehlt
Austauschstromdichte i₀Weder im Korpus noch im Gattungs-Priorfehlt
Durchtrittsfaktor αWeder im Korpus noch im Gattungs-Priorfehlt
Tafel-SteigungWeder im Korpus noch im Gattungs-Priorfehlt

Korpuswerte sind der Median unterschiedlicher Messungen, mit der 10–90-%-Streuung, wenn sie sich unterscheiden. Werte des Gattungs-Priors tragen einen kuratierten Bereich, kein Perzentil.

Nicht gebündelt: 28 Duplikate, 10 abiotisch, 4 verworfene Artefakte, 3 nur als Beleg, 2 beobachtete Maxima, nicht gefittet, 2 an anderem Substrat, 1 nicht modellierte Parameter.

Belegzeilen (63)

In die Schätzungen gebündelt (13)

  1. Halbsättigungskonstante KsKs2,9 mMacetateGeprüftArtzeileKonfidenz 0,97

    Competition of two highly specialized and efficient acetoclastic electroactive bacteria for acetate in biofilm anode of microbial electrolysis cell · 2021 · 10.1038/s41522-021-00218-3

    “Results suggested that both cultures exhibited a Monod-like saturation curve (Fig. 6) as reported earlier for other electrochemically active bacteria, with higher jmax (10.7 ± 0.4 A/m²) and lower KS, app (2 ± 0.15 mM) estimated for D. acetexigens than G. sulfurreducens biofilms (jmax: 9.6 ± 0.2 A/m² and KS, app: 2.9 ± 0.2 mM).”

    Km des Stroms über dem Substrat, als Ks des Stroms gebündelt (nicht als Monod-Wachstums-Ks)

  2. Max. spezifische Wachstumsrate μmaxdoubling_time9,7 hacetateGeprüftArtzeileKonfidenz 0,95

    Electron Donors Supporting Growth and Electroactivity of Geobacter sulfurreducens Anode Biofilms · 2012 · 10.1128/aem.06782-11

    “cultures supplemented with 30 mM formate (concentrations like those previously tested [4]) grew and reduced all the Fe(III), though doubling times (17.3 ± 7.9 h) were higher than those supplemented with equimolar concentrations of carbon in the 15 mM acetate controls (9.7 ± 0.2 h).”

    Verdopplungszeit, als ln 2 / t_d in μmax gebündelt

  3. Halbsättigungskonstante KsKs2,9 mMacetateGeprüftArtzeileKonfidenz 0,8

    s41522-021-00218-3 - Competition of two highly specialized and efficient acetoclastic electroactive b · 2021

    “The apparent Monod kinetic parameters reveal that DA possesses higher j max (10.7 ± 0.4 A/m 2 ) and lower K S, app (2 ± 0.15 mM) compared to GS biofilms (j max : 9.6 ± 0.2 A/m 2 and K S, app : 2.9 ± 0.2 mM).”

    Km des Stroms über dem Substrat, als Ks des Stroms gebündelt (nicht als Monod-Wachstums-Ks)

  4. Halbsättigung des Stroms Ks (Strom)K_M0,35 mMacetateNicht geprüftGattungszeileKonfidenz 0,93

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “KM = 0.28-0.42 mM (2nd cycle) || range: [0.28, 0.42] || canonical_organism: geobacter_sulfurreducens_pca || canonical_substrate: acetate”

    Km des Stroms über dem Substrat, als Ks des Stroms gebündelt (nicht als Monod-Wachstums-Ks)

  5. Max. Stromdichte jmaxvmax0,0034 mmol/h/cm²acetateNicht geprüftGattungszeileKonfidenz 0,92

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “vmax = 0.0031-0.0037 mmol h⁻¹ cm⁻² (2nd cycle) || range: [0.0031, 0.0037] || canonical_organism: geobacter_sulfurreducens_pca || canonical_substrate: acetate”

    Substrataufnahmefluss, als Strom bei 100 % Coulomb-Effizienz in jmax gebündelt (eine Obergrenze)

  6. Max. Stromdichte jmaxvmax0,0042 mmol Ac⁻ h⁻¹ cm⁻²acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “vmax,Ac and KM,Ac, decreased from 0.0042–0.0051 mmol Ac−h−1 cm−2 to 0.0031–0.0037 mmol Ac−h−1 cm−2”

    Substrataufnahmefluss, als Strom bei 100 % Coulomb-Effizienz in jmax gebündelt (eine Obergrenze)

  7. Max. Stromdichte jmaxvmax0,0051 mmol Ac⁻ h⁻¹ cm⁻²acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “vmax,Ac and KM,Ac, decreased from 0.0042–0.0051 mmol Ac−h−1 cm−2 to 0.0031–0.0037 mmol Ac−h−1 cm−2”

    Substrataufnahmefluss, als Strom bei 100 % Coulomb-Effizienz in jmax gebündelt (eine Obergrenze)

  8. Max. Stromdichte jmaxvmax0,0031 mmol Ac⁻ h⁻¹ cm⁻²acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “vmax,Ac and KM,Ac, decreased from 0.0042–0.0051 mmol Ac−h−1 cm−2 to 0.0031–0.0037 mmol Ac−h−1 cm−2”

    Substrataufnahmefluss, als Strom bei 100 % Coulomb-Effizienz in jmax gebündelt (eine Obergrenze)

  9. Max. Stromdichte jmaxvmax0,0037 mmol Ac⁻ h⁻¹ cm⁻²acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “vmax,Ac and KM,Ac, decreased from 0.0042–0.0051 mmol Ac−h−1 cm−2 to 0.0031–0.0037 mmol Ac−h−1 cm−2”

    Substrataufnahmefluss, als Strom bei 100 % Coulomb-Effizienz in jmax gebündelt (eine Obergrenze)

  10. Halbsättigung des Stroms Ks (Strom)K_M1,02 mM Ac⁻acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “KM,Ac, decreased from 1.02–2.61 mM Ac− to 0.28–0.42 mM Ac−”

    Km des Stroms über dem Substrat, als Ks des Stroms gebündelt (nicht als Monod-Wachstums-Ks)

  11. Halbsättigung des Stroms Ks (Strom)K_M2,61 mM Ac⁻acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “KM,Ac, decreased from 1.02–2.61 mM Ac− to 0.28–0.42 mM Ac−”

    Km des Stroms über dem Substrat, als Ks des Stroms gebündelt (nicht als Monod-Wachstums-Ks)

  12. Halbsättigung des Stroms Ks (Strom)K_M0,28 mM Ac⁻acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “KM,Ac, decreased from 1.02–2.61 mM Ac− to 0.28–0.42 mM Ac−”

    Km des Stroms über dem Substrat, als Ks des Stroms gebündelt (nicht als Monod-Wachstums-Ks)

  13. Halbsättigung des Stroms Ks (Strom)K_M0,42 mM Ac⁻acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “KM,Ac, decreased from 1.02–2.61 mM Ac− to 0.28–0.42 mM Ac−”

    Km des Stroms über dem Substrat, als Ks des Stroms gebündelt (nicht als Monod-Wachstums-Ks)

Aufgelistet, nicht gebündelt (40)

Kein Parameter, den der Simulator modelliert (1)

  1. lag_phase1 houracetate-fumarateNicht geprüftArtzeileKonfidenz 0,95

    Cation-driven envelope dynamics modulate outer membrane vesiculation and extracellular electron transfer in Geobacter · 2026 · 10.21203/rs.3.rs-8864095/v1

    “The DB-grown cells reproducibly underwent slightly longer (> 1 hour) lag phases yet, once acclimated, they doubled faster than in the NB medium.”

Eine erreichte Stromdichte, nicht das gefittete Sättigungs-jmax: aufgelistet, nie gebündelt (2)

  1. Max. Stromdichte jmaxI_max29,5 A/m²acetateNicht geprüftArtzeileKonfidenz 0,95

    A microfluidic study of acetate conversion kinetics in a microbial electrolysis cell: The role of age, concentration and flow on biofilm permeability · 2024 · 10.1016/j.snb.2024.135779

    “current densities up to 29.5 A/m² recorded across multiple flow conditions || canonical_organism: geobacter_sulfurreducens_pca || canonical_substrate: acetate”
  2. Max. Stromdichte jmaxI_max29,5 A/m²acetateNicht geprüftArtzeileKonfidenz 0,95

    A microfluidic study of acetate conversion kinetics in a microbial electrolysis cell: The role of age, concentration and flow on biofilm permeability · 2024 · 10.1016/j.snb.2024.135779

    “current densities up to 29.5 A/m² recorded across multiple flow conditions || canonical_organism: geobacter_sulfurreducens_pca || canonical_substrate: acetate”

An einem anderen Substrat als der gebündelten Basis gemessen (2)

  1. Max. spezifische Wachstumsrate μmaxdoubling_time45,1 hformateGeprüftArtzeileKonfidenz 0,95

    Electron Donors Supporting Growth and Electroactivity of Geobacter sulfurreducens Anode Biofilms · 2012 · 10.1128/aem.06782-11

    “Increasing the concentration of formate to 60 mM to provide the same amount of electrons as in 15 mM acetate did not improve growth but rather slowed it down, with generation times in triplicate cultures averaging 45.1 (6.1) h.”
  2. Max. spezifische Wachstumsrate μmaxdoubling_time90 hlactateGeprüftArtzeileKonfidenz 0,95

    Electron Donors Supporting Growth and Electroactivity of Geobacter sulfurreducens Anode Biofilms · 2012 · 10.1128/aem.06782-11

    “average doubling times with lactate (90 ± 12 h) were ca. 5- and 9-times greater than with formate and acetate, respectively. Hence, although at high-enough redox potential G. sulfurreducens can also use lactate as an electron donor, growth is slower than with acetate or formate.”

Bekanntes Extraktionsartefakt (Wachstumsrate in mA/h oder eine 0 ohne Einheit), verworfen (4)

  1. Max. spezifische Wachstumsrate μmaxmu_max0,12 mA/hacetateNicht geprüftArtzeileKonfidenz 0,8

    Electron Donors Supporting Growth and Electroactivity of Geobacter sulfurreducens Anode Biofilms · 2012 · 10.1128/aem.06782-11

    “The rate of current increase, which correlates with the exponential phase of biofilm growth (22), averaged 0.12 mA h⁻¹ in triplicate BESs”
  2. Max. spezifische Wachstumsrate μmaxmu_max0,12 mA/hacetateNicht geprüftArtzeileKonfidenz 0,8

    Electron Donors Supporting Growth and Electroactivity of Geobacter sulfurreducens Anode Biofilms · 2012 · 10.1128/aem.06782-11

    “The rate of current increase, which correlates with the exponential phase of biofilm growth (22), averaged 0.12 mA h⁻¹ in triplicate BESs”
  3. Max. spezifische Wachstumsrate μmaxmu_max0,12 mA/hacetateNicht geprüftArtzeileKonfidenz 0,8

    Electron Donors Supporting Growth and Electroactivity of Geobacter sulfurreducens Anode Biofilms · 2012 · 10.1128/aem.06782-11

    “The rate of current increase, which correlates with the exponential phase of biofilm growth (22), averaged 0.12 mA h⁻¹ in triplicate BESs”
  4. Max. spezifische Wachstumsrate μmaxmu_max0,12 mA/hacetateNicht geprüftArtzeileKonfidenz 0,8

    Electron Donors Supporting Growth and Electroactivity of Geobacter sulfurreducens Anode Biofilms · 2012 · 10.1128/aem.06782-11

    “The rate of current increase, which correlates with the exponential phase of biofilm growth (22), averaged 0.12 mA h⁻¹ in triplicate BESs”

Duplikat einer bereits gezählten Messung aus derselben Publikation (28)

  1. Halbsättigungskonstante KsKs2,9 mMacetateGeprüftArtzeileKonfidenz 0,8

    Competition of two highly specialized and efficient acetoclastic electroactive bacteria for acetate in biofilm anode of microbial electrolysis cell · 2021 · 10.1038/s41522-021-00218-3

    “The apparent Monod kinetic parameters reveal that DA possesses higher jmax (10.7 ± 0.4 A/m²) and lower KS, app (2 ± 0.15 mM) compared to GS biofilms (jmax: 9.6 ± 0.2 A/m² and KS, app: 2.9 ± 0.2 mM).”
  2. Halbsättigung des Stroms Ks (Strom)K_M0,35 mMacetateNicht geprüftGattungszeileKonfidenz 0,93

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “KM = 0.28-0.42 mM (2nd cycle) || range: [0.28, 0.42] || canonical_organism: geobacter_sulfurreducens_pca || canonical_substrate: acetate”
  3. Max. Stromdichte jmaxvmax0,0034 mmol/h/cm²acetateNicht geprüftGattungszeileKonfidenz 0,92

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “vmax = 0.0031-0.0037 mmol h⁻¹ cm⁻² (2nd cycle) || range: [0.0031, 0.0037] || canonical_organism: geobacter_sulfurreducens_pca || canonical_substrate: acetate”
  4. Max. Stromdichte jmaxvmax0,0042 mmol Ac⁻ h⁻¹ cm⁻²acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “vmax,Ac and KM,Ac, decreased from 0.0042–0.0051 mmol Ac−h−1 cm−2 to 0.0031–0.0037 mmol Ac−h−1 cm−2”
  5. Max. Stromdichte jmaxvmax0,0051 mmol Ac⁻ h⁻¹ cm⁻²acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “vmax,Ac and KM,Ac, decreased from 0.0042–0.0051 mmol Ac−h−1 cm−2 to 0.0031–0.0037 mmol Ac−h−1 cm−2”
  6. Max. Stromdichte jmaxvmax0,0031 mmol Ac⁻ h⁻¹ cm⁻²acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “vmax,Ac and KM,Ac, decreased from 0.0042–0.0051 mmol Ac−h−1 cm−2 to 0.0031–0.0037 mmol Ac−h−1 cm−2”
  7. Max. Stromdichte jmaxvmax0,0037 mmol Ac⁻ h⁻¹ cm⁻²acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “vmax,Ac and KM,Ac, decreased from 0.0042–0.0051 mmol Ac−h−1 cm−2 to 0.0031–0.0037 mmol Ac−h−1 cm−2”
  8. Halbsättigung des Stroms Ks (Strom)K_M1,02 mM Ac⁻acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “KM,Ac, decreased from 1.02–2.61 mM Ac− to 0.28–0.42 mM Ac−”
  9. Halbsättigung des Stroms Ks (Strom)K_M2,61 mM Ac⁻acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “KM,Ac, decreased from 1.02–2.61 mM Ac− to 0.28–0.42 mM Ac−”
  10. Halbsättigung des Stroms Ks (Strom)K_M0,28 mM Ac⁻acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “KM,Ac, decreased from 1.02–2.61 mM Ac− to 0.28–0.42 mM Ac−”
  11. Halbsättigung des Stroms Ks (Strom)K_M0,42 mM Ac⁻acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “KM,Ac, decreased from 1.02–2.61 mM Ac− to 0.28–0.42 mM Ac−”
  12. Max. Stromdichte jmaxvmax0,0042 mmol Ac⁻ h⁻¹ cm⁻²acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “vmax,Ac and KM,Ac, decreased from 0.0042–0.0051 mmol Ac−h−1 cm−2 to 0.0031–0.0037 mmol Ac−h−1 cm−2”
  13. Max. Stromdichte jmaxvmax0,0051 mmol Ac⁻ h⁻¹ cm⁻²acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “vmax,Ac and KM,Ac, decreased from 0.0042–0.0051 mmol Ac−h−1 cm−2 to 0.0031–0.0037 mmol Ac−h−1 cm−2”
  14. Max. Stromdichte jmaxvmax0,0031 mmol Ac⁻ h⁻¹ cm⁻²acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “vmax,Ac and KM,Ac, decreased from 0.0042–0.0051 mmol Ac−h−1 cm−2 to 0.0031–0.0037 mmol Ac−h−1 cm−2”
  15. Max. Stromdichte jmaxvmax0,0037 mmol Ac⁻ h⁻¹ cm⁻²acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “vmax,Ac and KM,Ac, decreased from 0.0042–0.0051 mmol Ac−h−1 cm−2 to 0.0031–0.0037 mmol Ac−h−1 cm−2”
  16. Halbsättigung des Stroms Ks (Strom)K_M1,02 mM Ac⁻acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “KM,Ac, decreased from 1.02–2.61 mM Ac− to 0.28–0.42 mM Ac−”
  17. Halbsättigung des Stroms Ks (Strom)K_M2,61 mM Ac⁻acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “KM,Ac, decreased from 1.02–2.61 mM Ac− to 0.28–0.42 mM Ac−”
  18. Halbsättigung des Stroms Ks (Strom)K_M0,28 mM Ac⁻acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “KM,Ac, decreased from 1.02–2.61 mM Ac− to 0.28–0.42 mM Ac−”
  19. Halbsättigung des Stroms Ks (Strom)K_M0,42 mM Ac⁻acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “KM,Ac, decreased from 1.02–2.61 mM Ac− to 0.28–0.42 mM Ac−”
  20. Max. Stromdichte jmaxvmax0,0042 mmol Ac⁻ h⁻¹ cm⁻²acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “vmax,Ac and KM,Ac, decreased from 0.0042–0.0051 mmol Ac−h−1 cm−2 to 0.0031–0.0037 mmol Ac−h−1 cm−2”
  21. Max. Stromdichte jmaxvmax0,0051 mmol Ac⁻ h⁻¹ cm⁻²acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “vmax,Ac and KM,Ac, decreased from 0.0042–0.0051 mmol Ac−h−1 cm−2 to 0.0031–0.0037 mmol Ac−h−1 cm−2”
  22. Max. Stromdichte jmaxvmax0,0031 mmol Ac⁻ h⁻¹ cm⁻²acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “vmax,Ac and KM,Ac, decreased from 0.0042–0.0051 mmol Ac−h−1 cm−2 to 0.0031–0.0037 mmol Ac−h−1 cm−2”
  23. Max. Stromdichte jmaxvmax0,0037 mmol Ac⁻ h⁻¹ cm⁻²acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “vmax,Ac and KM,Ac, decreased from 0.0042–0.0051 mmol Ac−h−1 cm−2 to 0.0031–0.0037 mmol Ac−h−1 cm−2”
  24. Halbsättigung des Stroms Ks (Strom)K_M1,02 mM Ac⁻acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “KM,Ac, decreased from 1.02–2.61 mM Ac− to 0.28–0.42 mM Ac−”
  25. Halbsättigung des Stroms Ks (Strom)K_M2,61 mM Ac⁻acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “KM,Ac, decreased from 1.02–2.61 mM Ac− to 0.28–0.42 mM Ac−”
  26. Halbsättigung des Stroms Ks (Strom)K_M0,28 mM Ac⁻acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “KM,Ac, decreased from 1.02–2.61 mM Ac− to 0.28–0.42 mM Ac−”
  27. Halbsättigung des Stroms Ks (Strom)K_M0,42 mM Ac⁻acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “KM,Ac, decreased from 1.02–2.61 mM Ac− to 0.28–0.42 mM Ac−”
  28. Halbsättigung des Stroms Ks (Strom)Km1,02 mM Ac⁻acetateGeprüftGattungszeileKonfidenz 0,85

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “The half-saturation concentration based on acetate uptake, KM,Ac, decreases from 1st to 2nd batch cycle (from 1.02–2.61 mM Ac− to 0.28–0.42 mM Ac−) indicating an increased affinity of the maturing biofilm for acetate that results in a more effective acetate uptake.”

Beleg zum Elektronentransfer, den keine Simulatorkonstante aufnimmt (E_m, k_het, R_ct …) (3)

  1. E_eq-0,4 V_vs_Ag_AgCl_3M_KClNicht geprüftGattungszeileKonfidenz 0,92

    Behavior of two-chamber microbial electrochemical systems started-up with different ion-exchange membrane separators · 2019 · 10.1016/j.biortech.2019.01.097

    “In the consecutive acetate feedings, EA got more negative and comparable for each MFCs (-0.4 ± 0.03 V)”
  2. E_eq-0,4 V_vs_Ag_AgCl_3M_KClNicht geprüftGattungszeileKonfidenz 0,92

    Behavior of two-chamber microbial electrochemical systems started-up with different ion-exchange membrane separators · 2019 · 10.1016/j.biortech.2019.01.097

    “In the consecutive acetate feedings, EA got more negative and comparable for each MFCs (-0.4 ± 0.03 V)”
  3. E_eq-0,4 V_vs_Ag_AgCl_3M_KClNicht geprüftGattungszeileKonfidenz 0,92

    Behavior of two-chamber microbial electrochemical systems started-up with different ion-exchange membrane separators · 2019 · 10.1016/j.biortech.2019.01.097

    “In the consecutive acetate feedings, EA got more negative and comparable for each MFCs (-0.4 ± 0.03 V)”

Abiotische Reaktionen, nicht der Organismus (10)

Elektrodenreaktionen, die die Publikation ohne den Elektronentransfer des Organismus gemessen hat (Sauerstoffreduktion, Wasserstoffentwicklung, Mediatoren, Enzyme). Zur Einordnung aufgelistet, nie gebündelt.

  1. Tafel-Steigungtafel_slope43 mV dec⁻¹GeprüftArtzeileKonfidenz 0,88

    Bioinspired Synthesis of Reduced Graphene Oxide-Wrapped Geobacter sulfurreducens as a Hybrid Electrocatalyst for Efficient Oxygen Evolution Reaction · 2019 · 10.1021/acs.chemmater.9b00394

    “The hybrid catalyst (i.e., Geobacter/rGO) produces a geometric current density of 10 mA cm⁻² at an overpotential of 270 mV versus the reversible hydrogen electrode with a Tafel slope of 43 mV dec⁻¹ and possesses high durability, as evidenced through 10 h of stability testing.”
  2. E_eq0,4 V_vs_Ag_AgCl_3M_KClNicht geprüftGattungszeileKonfidenz 0,92

    Behavior of two-chamber microbial electrochemical systems started-up with different ion-exchange membrane separators · 2019 · 10.1016/j.biortech.2019.01.097

    “EC for AEM-MFC was stabilized at +0.40 ± 0.04 V after the 18th day”
  3. E_eq0,33 V_vs_Ag_AgCl_3M_KClNicht geprüftGattungszeileKonfidenz 0,92

    Behavior of two-chamber microbial electrochemical systems started-up with different ion-exchange membrane separators · 2019 · 10.1016/j.biortech.2019.01.097

  4. E_eq0,27 V_vs_Ag_AgCl_3M_KClNicht geprüftGattungszeileKonfidenz 0,92

    Behavior of two-chamber microbial electrochemical systems started-up with different ion-exchange membrane separators · 2019 · 10.1016/j.biortech.2019.01.097

  5. E_eq0,4 V_vs_Ag_AgCl_3M_KClNicht geprüftGattungszeileKonfidenz 0,92

    Behavior of two-chamber microbial electrochemical systems started-up with different ion-exchange membrane separators · 2019 · 10.1016/j.biortech.2019.01.097

    “EC for AEM-MFC was stabilized at +0.40 ± 0.04 V after the 18th day”
  6. E_eq0,33 V_vs_Ag_AgCl_3M_KClNicht geprüftGattungszeileKonfidenz 0,92

    Behavior of two-chamber microbial electrochemical systems started-up with different ion-exchange membrane separators · 2019 · 10.1016/j.biortech.2019.01.097

  7. E_eq0,27 V_vs_Ag_AgCl_3M_KClNicht geprüftGattungszeileKonfidenz 0,92

    Behavior of two-chamber microbial electrochemical systems started-up with different ion-exchange membrane separators · 2019 · 10.1016/j.biortech.2019.01.097

  8. E_eq0,4 V_vs_Ag_AgCl_3M_KClNicht geprüftGattungszeileKonfidenz 0,92

    Behavior of two-chamber microbial electrochemical systems started-up with different ion-exchange membrane separators · 2019 · 10.1016/j.biortech.2019.01.097

    “EC for AEM-MFC was stabilized at +0.40 ± 0.04 V after the 18th day”
  9. E_eq0,33 V_vs_Ag_AgCl_3M_KClNicht geprüftGattungszeileKonfidenz 0,92

    Behavior of two-chamber microbial electrochemical systems started-up with different ion-exchange membrane separators · 2019 · 10.1016/j.biortech.2019.01.097

  10. E_eq0,27 V_vs_Ag_AgCl_3M_KClNicht geprüftGattungszeileKonfidenz 0,92

    Behavior of two-chamber microbial electrochemical systems started-up with different ion-exchange membrane separators · 2019 · 10.1016/j.biortech.2019.01.097

Prior auf Gattungsebene: Geobacter sulfurreducens

Ein Prior auf Gattungsebene fasst die ganze Gattung zusammen; er ist keine Messung an diesem Stamm.

Konstanten, die die Simulation antreiben

Jede Konstante stammt aus den Korpuszeilen, sonst aus dem Gattungs-Prior. Ein eingegebener Wert füllt nur eine Lücke; er überschreibt nie einen Beleg.

Lücke füllen (5)

Konstanten in diesem Lauf

Max. spezifische Wachstumsrate μmax
0,0715 h⁻¹DB-Zeilen
Halbsättigungskonstante Ks
80 mg/LGattungs-Prior
Biomasseausbeute Y
0,07 g/gGattungs-Prior
Absterbekoeffizient kd
—fehlt
Biofilmdichte
—fehlt
Max. Stromdichte jmax
7,93 A/m²DB-Zeilen
Halbsättigung des Stroms Ks (Strom)
60,22 mg/LDB-Zeilen
Halbsättigungspotenzial E_KA
—fehlt
Austauschstromdichte i₀
—fehlt
Durchtrittsfaktor α
—fehlt

Elektronenfluss

Dieser Organismus gilt als fähig, Elektronen in beide Richtungen auszutauschen; wählen Sie, welche der Lauf modelliert.

Szenario – Ihre Werte, keine Belege

Acetat zu Beginn, mg/L1.000 mg/L
Anodenpotenzial gegen SHE0 V
Dauer72 h
Anfängliche anhaftende Biomasse0,1 g/m²
Anodenfläche je Flüssigkeitsvolumen100 m²/m³
Reaktorbetrieb
Voreinstellungen aus den Belegen
  • Sättigend: S₀ = 10 × Ks = 800 mg/L.
  • Halbsättigung: S₀ = Ks = 80 mg/L.

Wachstumssimulation

Szenario: Acetat zu Beginn 1.000 mg/L · Anfängliche anhaftende Biomasse 0,1 g/m² · Anodenfläche je Flüssigkeitsvolumen 100 m²/m³ · Dauer 72 h · Satzbetrieb. Ihre Werte, keine Belege.

0,8g/m²
Maximale Biomasse
32,1h
Zeit bis 90 % Substratabbau
1,6A/m²
Maximale Stromdichte
Anhaftende Biomasseg/m²
Anhaftende Biomasse über 72 h: von 0,1 g/m² auf 0,8 g/m².00,50204060h
Acetat in der Lösungmg/L
Acetat in der Lösung über 72 h: von 1.000 mg/L auf 9,04e-16 mg/L.05001.0000204060h
StromdichteA/m²Stöchiometrische Obergrenze: 100 % coulombsche Effizienz, keine Potenzialabhängigkeit.
Stromdichte über 72 h: von 0,312 A/m² auf 3,05e-17 A/m².0120204060h
  • Substratgesättigtes Wachstum
  • Verlangsamung
  • Stationär

Monod-Wachstum kennt keine Lag-Phase; die Bänder markieren, wo die Nettowachstumsrate nahe ihrem Maximum liegt, fällt, nahe null oder negativ ist.

Hinweise des Simulators
  • Kein Absterbekoeffizient: kein endogener Abbauterm, das Wachstum ist eine Obergrenze.
  • Keine Biofilmdichte: die Dicke wird nicht berechnet.
  • Substratfluss auf Acetat: der stöchiometrische Strom der Aufnahme bei 100 % coulombscher Effizienz (f_e = 0,909), ohne Potenzialabhängigkeit und ohne Erhaltungs- oder Abbauelektronen, eine Obergrenze.

Kinetik des Elektronentransfers

Zeitpunktt = 29,1 h

Verschiebt Arbeitspunkt und Umsatz; beginnt beim maximalen Strom.

Keine elektrochemischen Konstanten: der Strom ist die stöchiometrische Obergrenze der Substrataufnahme, ohne Potenzialabhängigkeit, daher gibt es keine Strom-Potenzial-Kurve.

Ein Nernst-Monod-Strom bräuchte zusätzlich Halbsättigungspotenzial E_KA.

Elektronensprünge zwischen Redoxzentren
ZELLEANODECbcLImcHPpcAOmcBOmaBOmaCOmbBOmbCOmcZOmcSe⁻ →

Zentren in Kettenreihenfolge: innere Membran → Periplasma → äußere Membran → extrazellulär, dann nach Mittelpunktspotenzial.

illustrativ, σ setzen für eine Rate

Dichte der Redoxzentren σ (angenommen, kein Beleg)nicht gesetzt

Triebkraft entlang der Elektronenkette

H⁺/H₂Acetat/CO₂Anode-0,5-0,4-0,3-0,2-0,10,00,10,20,31234
■ Cytochrom · ○ ShuttleE°′ (V vs. SHE)

Trägerliste und Mittelpunktspotenziale: Elektronentransfer

Jeder Schritt ist E_nächster − E_aktuell, endend bei einem Anodenpotenzial von 0 V vs SHE; positiv heißt bergab.

  1. PpcA → OmcB−40 mV · bergauf
  2. OmcB → OmcZ−30 mV · bergauf
  3. OmcZ → OmcS+8 mV · bergab
  4. OmcS → Anode+212 mV · bergab

Nicht in der Kette, kein kuratiertes Mittelpunktspotenzial: CbcL, ImcH, PpcB, PpcD, OmaB, OmaC, OmbB, OmbC, OmcC, OmcE.

Diese Kurven sind eine Monod- und Nernst-Monod-Idealisierung (nach Marcus et al. 2007 und Torres et al. 2008), parametrisiert allein durch die oben aufgeführten Konstanten: jede trägt ihr n und ihre Streuung (10–90 % für Korpuswerte, ein kuratierter Bereich für den Gattungs-Prior), und eine Konstante aus einer einzigen Messung hat gar keine Streuung. Keine Diffusion im Biofilm, keine Ablösung, keine Aufteilung nach coulombscher Effizienz. Die Szenariowerte sind Ihre, keine Belege.

05 · Leistung

Leistung

Berichtete elektrochemische Leistung, die Rolle im Reaktor und was der Organismus produziert.

Elektrogen: Strong
1.900mW/m²
Max power density
Bereich 800–3.900 · pro projected anode area
4A/m²
Max current density
Bereich 1–7,6 · pro projected anode area
85%
Coulombic efficiency
Bereich 60–95
Onset potential
-0,17 V vs SHE

Materialien, mit denen dieser Organismus kombiniert wird (5)

Elektrodenmaterialien, die im Materialkatalog mit diesem Organismus verknüpft sind. Ein Spitzenwert ist der beste berichtete Wert für die Kombination; die Konfidenz gibt an, wie gut die Kombination selbst belegt ist.

MaterialEingesetzt alsBiofilmSpitzenleistungmW/m²SpitzenstrommA/m²KonfidenzQuelle
Graphite brushAnodenmaterial—2.400—HochLogan et al., ES&T 2007 10.1021/es062644yHeat-treated graphite fibres (Geobacter biofilm)zugeordnet über Gattungs-Tag: Geobacter
PANI@CNT spongeAnodenmaterial—7.549—HochPANI@CNT sponge (Geobacter), 7549 mW/m² — DOI pendingPore-matched PANI shell on CNT sponge; 91.7 % coulombic efficiencyzugeordnet über Gattungs-Tag: Geobacter
Carbon clothAnodenmaterial———MittelLogan 2008 (Microbial Fuel Cells)Unmodified — surface oxidation lifts to 800 mW/m²zugeordnet über Gattungs-Tag: Geobacter
Carbon feltAnodenmaterial———MittelUnmodified baseline — see Phase C entries for activated variantszugeordnet über Gattungs-Tag: Geobacter
PDA-Fe₃O₄ / carbon feltAnodenmaterial———MittelZhang et al., Chemosphere 2024 10.1016/j.chemosphere.2024.141764Polydopamine pre-coat → in-situ Fe₃O₄ nanoparticle depositionzugeordnet über Gattungs-Tag: Geobacter

Rolle im Reaktor

Kammer: AnodeAnode: primary current producer
Typische relative Häufigkeit im Biofilm60 (30–95) %
0100 %

Often dominates acetate-fed anode biofilms after enrichment.

Substrat → Produkt (1)

  • acetateergibt
    • CO2

    anaerobic, anode as electron acceptor · Ausbeute 8 electrons/mol acetate · Complete oxidation to CO2.

06 · Ökologie & Biofilm

Ökologie & Biofilm

Wie der Organismus auf einer Elektrode lebt, mit welchen Partnern er kooperiert und wo er in der Natur vorkommt.

Biofilm

  • Bildet Biofilm: ja
Biofilmdicke50 (20–80) µm
0100 µm

Biofilm-Leitfähigkeit

0,05 (0,005–5) S/m

Bevorzugte Elektrodenmaterialien

  • graphite felt
  • carbon cloth
  • carbon brush
  • stainless steel mesh

Besiedelbare Oberfläche

Anteil der gemessenen Porenwand in Poren, die mindestens eine Zelle breit sind: Wände, die eine Zelle dieser Breite erreichen kann.

Zellbreite 0,5 (0,4–0,7) µm · Kuratierter Morphologie-Eintrag (morphology.cell_width_um)

Partner im Elektronenaustausch (3)

Tritt häufig gemeinsam auf mit

  • Methanothrix harundinacea
  • Methanosarcina spp.
  • Pelobacter spp.

Vermittlung über leitfähige Minerale

  • Vermittelt über leitfähige Minerale: ja
  • Magnetite
  • Biochar

Magnetite stimulates DIET with methanogen partners; biochar similarly enhances syntrophic acetate/butyrate degradation (Liu 2015, Cruz Viggi 2014).

Ökosysteme

  • Freshwater
  • Subsurface
  • Engineered MES

Isolierungsquellen

  • subsurface sediment, Norman, Oklahoma USA

07 · Anwendungen, Stammentwicklung & Sicherheit

Anwendungen, Stammentwicklung & Sicherheit

Wo der Organismus bereits eingesetzt wurde, wie gut er sich gentechnisch verändern lässt und welche Handhabung er erfordert.

Anwendungen (4)

  • Bioremediation metals · Pilot scale
    TRL 6/9
  • Wastewater treatment · Pilot scale
    TRL 5/9
  • Bioelectricity generation · Bench scale
    TRL 4/9
  • Research model organism · Lab pure culture

Stammentwicklung

Synthetic biology chassisIndustrielle Relevanz 5/5

Reaktorkompatibilität

  • MFC dual chamber
  • MEC
  • Sediment MFC
Scale demonstrated
Pilot

Verlauf der Stammentwicklung (3)

  1. 1994 Wild type isolation

    Type strain isolated from Potomac River sediment.

    1994 · Caccavo F, et al. 1994

  2. 2009 Evolution

    Adaptive lab evolution under high-current selection (KN400 strain).

    Max current density 4 → 7,6 A/m2

    2009 · Yi H, et al. (2009). KN400 strain selection.DOI Spawned the geobacter_sulfurreducens_kn400 strain record (planned but not yet seeded).

  3. 2014 Engineered

    Markerless deletion of omcZ; abolishes high-current biofilm phenotype.

    2014 · Inoue K, et al. (2010); Liu Y, et al. (2014).DOI

Genetik

  • Genetisch zugänglich: ja

Zentrale EET-Gene

  • pilA
  • omcB
  • omcC
  • omcS
  • omcZ
  • omcE
  • ppcA
  • imcH
  • cbcL

qPCR-Zielgene

  • pilA
  • omcB
  • omcZ
  • omcS

Transformationsmethoden

  • Electroporation
Available genetic tools
  • markerless deletion
  • pRG5 plasmid
  • pCM66 derivatives
  • CRISPR-Cas9

Omics-Studien (2)

  • Transcriptomics RNA seq anode biofilm · 2012DOI

    Anode-biofilm vs Fe(III) citrate transcriptome.

  • Proteomics Shotgun proteomics anode · 2012DOI

Betrieb

Stabiler Betrieb2.000 (500–5.000) h
010.000 h
Fouling resistance
High
Load change sensitivity
Low
Recommended inoculation
Pre-grown anode biofilm transfer or planktonic seed at OD600 0.05–0.1 with acetate poising.
Pure vs mixed performance delta
1

Kommerzielle Nutzung

Strain itself is unencumbered; specific engineered variants may be IP-protected.

Biologische Sicherheit

BSL-1
  • Pathogen: nein

Modellierungsressourcen

  • Genomweites Stoffwechselmodell: ja
  • Kinetisches Modell: ja
  • Biofilmmodell: ja
  • iAF987 (Feist et al. 2014)

Verknüpftes GEM: iAF987

08 · Quellen & Datenqualität

Quellen & Datenqualität

Jeder Wert oben lässt sich auf eine Quelle zurückführen. So vollständig und so belastbar ist der Datensatz.

Qualität des Datensatzes

ComprehensiveKonfidenz: HighKuratiert: manual

Literaturstand 2026-04-26 · Schema v1.2.0 · aktualisiert 2026-10-31 · importiert 2026-04-28

Konfidenz je Feld

Engineering history
High
Genome metadata.size (bp)
High
Bibliometrics.total publications
Medium
EET mechanism.direct transfer.cytochromes
High
Electrochemical performance.max current density
High

Publikationen zu diesem Organismus (200)

Publikationen der Forschungsbibliothek, deren Text diesen Organismus nennt, die neuesten zuerst. Der Hinweis zeigt die stärkste Nennung je Publikation.

  1. Cation-driven envelope dynamics modulate outer membrane vesiculation and extracellular electron transfer in Geobacter
    2026 · Research SquareNiedrige Konfidenz
  2. Propionate oxidation by <i>Geobacter sulfurreducens</i> is electron acceptor dependent
    2026 · bioRxiv (Cold Spring Harbor Laboratory)Hohe Konfidenz
  3. Subcellular thiol functional group distribution in Geobacter sulfurreducens determined by Hg LIII-edge EXAFS
    2026 · Frontiers in MicrobiologyHohe Konfidenz
  4. The Restorative Effects of Electron Mediators on the Formation of Electroactive Biofilms in Geobacter sulfurreducens
    2026 · MicroorganismsHohe Konfidenz
  5. Trends in genetic and metabolic engineering of Geobacter sulfurreducens for bioelectrochemical systems: a bibliometric analysis.
    2026 · Archives of microbiologyHohe Konfidenz
  6. Restorative Effects of Electron Mediator on the Formation of Electroactive Biofilms in &lt;em&gt;Geobacter sulfurreducens&lt;/em&gt;
    2025 · Preprints.orgHohe Konfidenz
  7. Microbial fuel cells: A sustainable approach for environmental remediation and green energy generation
    2025 · Plant Science TodayNiedrige Konfidenz
  8. The Exploitation of Single-Chambered Microbial Fuel Cells for PET Removal in Water.
    2025 · MicroorganismsNiedrige Konfidenz
  9. A Bundled Antiparallel Cytochrome Nanowire Structure Suggests Roles in Cell-Cell Electron Transfer and Biofilm Formation.
    2025 · bioRxiv : the preprint server for biologyNiedrige Konfidenz
  10. Influence of support materials on the electroactive behavior, structure and gene expression of wild type and GSU1771-deficient mutant of Geobacter sulfurreducens biofilms.
    2025 · Environmental science and pollution research internationalHohe Konfidenz
  11. Transcriptional response to elemental sulfur in <i>Geobacter sulfurreducens</i>
    2025 · Bioscience, Biotechnology, and BiochemistryHohe Konfidenz
  12. Electron transport across the cell envelope via multiheme c-type cytochromes in Geobacter sulfurreducens
    2025 · Frontiers in ChemistryHohe Konfidenz

Die 12 neuesten von 200. Forschung nach diesem Organismus durchsuchen

Referenzen (5)

  1. Caccavo F, et al. (1994). Geobacter sulfurreducens sp. nov. Appl Environ Microbiol 60:3752-3759.PMID 7527204
  2. Bond DR, Lovley DR (2003). Electricity production by Geobacter sulfurreducens attached to electrodes. Appl Environ Microbiol 69:1548-1555.doi:10.1128/AEM.69.3.1548-1555.2003
  3. Reguera G, et al. (2005). Extracellular electron transfer via microbial nanowires. Nature 435:1098-1101.doi:10.1038/nature03661
  4. Logan BE, et al. (2019). Electroactive microorganisms in BES. Nat Rev Microbiol 17:307-319.doi:10.1038/s41579-019-0173-x
  5. Wang F, et al. (2019). Structure of microbial nanowires reveals stacked hemes. Cell 177:361-369.

Bibliometrie

1.500
Publikationen
2
Aktive Forschungsgruppen
1
Markierte Widersprüche
PILabCountry
Derek R. LovleyLovley LabUSA
Nikhil S. MalvankarMalvankar LabUSA
NotesTopicConflicting DOIs
Reguera 2005 reported PilA pili as nanowires; Wang 2019 demonstrated OmcS cytochrome filaments. Current consensus: OmcS/OmcZ filaments are the primary nanowires; PilA pilin is a secretion machine.Pilus vs cytochrome-filament identity of conductive nanowires10.1038/nature03661, 10.1016/j.cell.2019.03.029
YearCitationDOI
2.012Lovley DR (2012). Electromicrobiology. Annu Rev Microbiol 66:391-409.—
2.019Logan BE, et al. (2019). Electroactive microorganisms in BES. Nat Rev Microbiol 17:307-319.10.1038/s41579-019-0173-x

Versionsverlauf

  1. 2026-04-27 · v1.2.0 · messai_curation
    • Added structured cytochromes[] inventory with localization, heme counts, midpoint potentials.
    • Added genome_metadata, isolation provenance, type strain flag.
    • Added engineering_history (KN400 ALE; omcZ knockout).
    • Added bibliometrics, omics_resources, conductive mineral mediation.
