TEM — Thin section of cells after exposure to Pt(II)Cl4²⁻; the dark surface deposits are platinum particles. Adapted from Maes S et al. (2017), PLoS ONE 12(1):e0169093, Fig. 3. Quelle · CC BY 4.0 · Cropped to the G. metallireducens / Pt(II)Cl4²⁻ panel; converted to WebP

Electrogen · DIET partner donor · Iron reducer

Geobacter metallireducens GS-15

Thermodesulfobacteriota · Desulfuromonadia · Geobacteraceae

ElektroaktivEET outwardTypstammBSL-1Datensatz: Comprehensive
  • Aromatic degrader
  • Uranium bioremediation
  • Tier 1
  • DIET donor
Outward
Elektronentransfer
elektroaktiv
30°C
Optimale Temperatur
wächst bei 25–35 °C
7
Optimaler pH-Wert
wächst bei pH 6,5–7,5
4Mb
Genomgröße

01 · Identität

Identität

Wo dieser Organismus im Stammbaum des Lebens steht, wie man ihn bezieht und wie eine Zelle aussieht.

Abstammungslinie

  1. DomäneBacteria
  2. ›PhylumThermodesulfobacteriota
  3. ›KlasseDesulfuromonadia
  4. ›OrdnungGeobacterales
  5. ›FamilieGeobacteraceae
  6. ›GattungGeobacter
  7. ›ArtGeobacter metallireducens GS-15

Früher klassifiziert als Deltaproteobacteria.

Stammsammlungen & Zugangsnummern

DSMZ
DSM 7210
ATCC
ATCC 53774
NCBI-Taxon
269799
Genom
GCF_000012585.1
Status
Typstamm

Isolierung

Isoliert aus Potomac River sediment, Maryland, USA von Lovley DR, Phillips EJP (1987).

Lovley DR, Phillips EJP (1988). Manganese inhibition of microbial iron reduction in anaerobic sediments.

Genom

4Mb
Genomgröße
59,5%
GC-Gehalt
Complete
Assemblierungsstufe

Zellmorphologie

Rod, Gram-negative (diderm)

  • Beweglich: ja
  • Pili: ja
  • Vesikel der äußeren Membran: nein
  • Sporenbildend: nein

02 · Elektronentransfer

Elektronentransfer

Wie Elektronen die Zellhülle überwinden – die Eigenschaft, die einen Mikroorganismus in einem elektrochemischen System nützlich macht.

ElektroaktivEET outward
ZELLEELEKTRODEAUSSENMEMBRAN-CYTOCHROMEPpcAOmcBe⁻NANODRAHT · PILA PILINe⁻DIET → M. acetivoranse⁻
Elektronen fließen nach außen: Zelle → Elektrode (Exoelektrogen)

Mechanismen

  • Außenmembran-Cytochrome: ja
  • Leitfähige Pili / Nanodrähte: ja

03 · Wachstumsbereich

Wachstumsbereich

Die Bedingungen, die dieser Organismus toleriert, wovon er sich ernährt und was er veratmet – das Betriebsfenster für einen Reaktor.

MesophileObligate anaerobeChemoorganoheterotroph
Temperature30 (25–35) °C
0100 °C
pH7 (6,5–7,5)
014

Energiestoffwechsel

Elektronendonatoren

  • Acetate
  • Ethanol
  • aromatic compounds

Elektronenakzeptoren

  • Fe(III)
  • Mn(IV)
  • U(VI)
  • Anode
  • Nitrate

Kohlenstoffquellen

  • Acetate
  • Ethanol
  • Benzoate
  • Toluene
  • Phenol
  • p-cresol
  • Butyrate
  • Propionate
  • Respiratorisch: ja
  • Fermentativ: nein

Stoffwechsel – Details

ATP synthase type
Proton dependent
Energy conservation mechanism
Oxidative phosphorylation

04 · Wachstums- & Elektronentransferkinetik

Wachstums- & Elektronentransferkinetik

Wie schnell dieser Organismus wächst und wie stark er Elektronen an eine Anode abgibt, wie das Korpus es berichtet, und was diese Konstanten ergeben, wenn man sie rechnet.

Kinetische Belege

Wachstums- und Stromkonstanten teilen eine Substratbasis: Acetat.

ParameterWertStreuungnQuelle
Aus dem Korpus · Median und 10–90-%-Streuung
Max. Stromdichte jmaxaus dem Substrataufnahmefluss bei 100 % Coulomb-Effizienz: eine Obergrenze7,93 A/m²6,9–10,165 · 1 PublikationDB-Zeilen
median of 5 measurement(s) from 1 paper(s); organisms: Geobacter spp., Geobacter spp. enrichment biofilm; substrate: acetate; 13 duplicate row(s) collapsed; 5 of 5 derived from substrate uptake flux × electrons per mole × F, the current at 100 % coulombic efficiency (an upper bound on j_max)
Halbsättigung des Stroms Ks (Strom)24,8 mg/L18,18–116,55 · 1 PublikationDB-Zeilen
median of 5 measurement(s) from 1 paper(s); apparent half-saturation of biofilm current (Michaelis-Menten Km), not Monod growth Ks; organisms: Geobacter spp., Geobacter spp. enrichment biofilm; substrate: acetate; 14 duplicate row(s) collapsed
Prior auf Gattungsebene · Median und kuratierter Bereich
Max. spezifische Wachstumsrate μmax0,06 h⁻¹0,03–0,123 Publikationen, kuratiertGattungs-Prior · 2 Quellen
Lovley DR, Phillips EJP (1988); rates derived from Fe(III)-reducing conditions.; range = curated low/high, not percentiles
Halbsättigungskonstante Ks90 mg/L20–2002 Publikationen, kuratiertGattungs-Prior · 2 Quellen
Sparse data; range borrowed in part from G. sulfurreducens.; range = curated low/high, not percentiles
Biomasseausbeute Y0,07 g/g0,04–0,12 Publikationen, kuratiertGattungs-Prior · 2 Quellen
Order-of-magnitude estimate.; range = curated low/high, not percentiles
Noch keine Belege
Absterbekoeffizient kdWeder im Korpus noch im Gattungs-Priorfehlt
Austauschstromdichte i₀Weder im Korpus noch im Gattungs-Priorfehlt
Durchtrittsfaktor αWeder im Korpus noch im Gattungs-Priorfehlt
Tafel-SteigungWeder im Korpus noch im Gattungs-Priorfehlt

Korpuswerte sind der Median unterschiedlicher Messungen, mit der 10–90-%-Streuung, wenn sie sich unterscheiden. Werte des Gattungs-Priors tragen einen kuratierten Bereich, kein Perzentil.

Nicht gebündelt: 27 Duplikate.

Belegzeilen (37)

In die Schätzungen gebündelt (10)

  1. Halbsättigung des Stroms Ks (Strom)K_M0,35 mMacetateNicht geprüftGattungszeileKonfidenz 0,93

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “KM = 0.28-0.42 mM (2nd cycle) || range: [0.28, 0.42] || canonical_organism: geobacter_sulfurreducens_pca || canonical_substrate: acetate”

    Km des Stroms über dem Substrat, als Ks des Stroms gebündelt (nicht als Monod-Wachstums-Ks)

  2. Max. Stromdichte jmaxvmax0,0034 mmol/h/cm²acetateNicht geprüftGattungszeileKonfidenz 0,92

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “vmax = 0.0031-0.0037 mmol h⁻¹ cm⁻² (2nd cycle) || range: [0.0031, 0.0037] || canonical_organism: geobacter_sulfurreducens_pca || canonical_substrate: acetate”

    Substrataufnahmefluss, als Strom bei 100 % Coulomb-Effizienz in jmax gebündelt (eine Obergrenze)

  3. Max. Stromdichte jmaxvmax0,0042 mmol Ac⁻ h⁻¹ cm⁻²acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “vmax,Ac and KM,Ac, decreased from 0.0042–0.0051 mmol Ac−h−1 cm−2 to 0.0031–0.0037 mmol Ac−h−1 cm−2”

    Substrataufnahmefluss, als Strom bei 100 % Coulomb-Effizienz in jmax gebündelt (eine Obergrenze)

  4. Max. Stromdichte jmaxvmax0,0051 mmol Ac⁻ h⁻¹ cm⁻²acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “vmax,Ac and KM,Ac, decreased from 0.0042–0.0051 mmol Ac−h−1 cm−2 to 0.0031–0.0037 mmol Ac−h−1 cm−2”

    Substrataufnahmefluss, als Strom bei 100 % Coulomb-Effizienz in jmax gebündelt (eine Obergrenze)

  5. Max. Stromdichte jmaxvmax0,0031 mmol Ac⁻ h⁻¹ cm⁻²acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “vmax,Ac and KM,Ac, decreased from 0.0042–0.0051 mmol Ac−h−1 cm−2 to 0.0031–0.0037 mmol Ac−h−1 cm−2”

    Substrataufnahmefluss, als Strom bei 100 % Coulomb-Effizienz in jmax gebündelt (eine Obergrenze)

  6. Max. Stromdichte jmaxvmax0,0037 mmol Ac⁻ h⁻¹ cm⁻²acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “vmax,Ac and KM,Ac, decreased from 0.0042–0.0051 mmol Ac−h−1 cm−2 to 0.0031–0.0037 mmol Ac−h−1 cm−2”

    Substrataufnahmefluss, als Strom bei 100 % Coulomb-Effizienz in jmax gebündelt (eine Obergrenze)

  7. Halbsättigung des Stroms Ks (Strom)K_M1,02 mM Ac⁻acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “KM,Ac, decreased from 1.02–2.61 mM Ac− to 0.28–0.42 mM Ac−”

    Km des Stroms über dem Substrat, als Ks des Stroms gebündelt (nicht als Monod-Wachstums-Ks)

  8. Halbsättigung des Stroms Ks (Strom)K_M2,61 mM Ac⁻acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “KM,Ac, decreased from 1.02–2.61 mM Ac− to 0.28–0.42 mM Ac−”

    Km des Stroms über dem Substrat, als Ks des Stroms gebündelt (nicht als Monod-Wachstums-Ks)

  9. Halbsättigung des Stroms Ks (Strom)K_M0,28 mM Ac⁻acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “KM,Ac, decreased from 1.02–2.61 mM Ac− to 0.28–0.42 mM Ac−”

    Km des Stroms über dem Substrat, als Ks des Stroms gebündelt (nicht als Monod-Wachstums-Ks)

  10. Halbsättigung des Stroms Ks (Strom)K_M0,42 mM Ac⁻acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “KM,Ac, decreased from 1.02–2.61 mM Ac− to 0.28–0.42 mM Ac−”

    Km des Stroms über dem Substrat, als Ks des Stroms gebündelt (nicht als Monod-Wachstums-Ks)

Aufgelistet, nicht gebündelt (27)

Duplikat einer bereits gezählten Messung aus derselben Publikation (27)

  1. Halbsättigung des Stroms Ks (Strom)K_M0,35 mMacetateNicht geprüftGattungszeileKonfidenz 0,93

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “KM = 0.28-0.42 mM (2nd cycle) || range: [0.28, 0.42] || canonical_organism: geobacter_sulfurreducens_pca || canonical_substrate: acetate”
  2. Max. Stromdichte jmaxvmax0,0034 mmol/h/cm²acetateNicht geprüftGattungszeileKonfidenz 0,92

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “vmax = 0.0031-0.0037 mmol h⁻¹ cm⁻² (2nd cycle) || range: [0.0031, 0.0037] || canonical_organism: geobacter_sulfurreducens_pca || canonical_substrate: acetate”
  3. Max. Stromdichte jmaxvmax0,0042 mmol Ac⁻ h⁻¹ cm⁻²acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “vmax,Ac and KM,Ac, decreased from 0.0042–0.0051 mmol Ac−h−1 cm−2 to 0.0031–0.0037 mmol Ac−h−1 cm−2”
  4. Max. Stromdichte jmaxvmax0,0051 mmol Ac⁻ h⁻¹ cm⁻²acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “vmax,Ac and KM,Ac, decreased from 0.0042–0.0051 mmol Ac−h−1 cm−2 to 0.0031–0.0037 mmol Ac−h−1 cm−2”
  5. Max. Stromdichte jmaxvmax0,0031 mmol Ac⁻ h⁻¹ cm⁻²acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “vmax,Ac and KM,Ac, decreased from 0.0042–0.0051 mmol Ac−h−1 cm−2 to 0.0031–0.0037 mmol Ac−h−1 cm−2”
  6. Max. Stromdichte jmaxvmax0,0037 mmol Ac⁻ h⁻¹ cm⁻²acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “vmax,Ac and KM,Ac, decreased from 0.0042–0.0051 mmol Ac−h−1 cm−2 to 0.0031–0.0037 mmol Ac−h−1 cm−2”
  7. Halbsättigung des Stroms Ks (Strom)K_M1,02 mM Ac⁻acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “KM,Ac, decreased from 1.02–2.61 mM Ac− to 0.28–0.42 mM Ac−”
  8. Halbsättigung des Stroms Ks (Strom)K_M2,61 mM Ac⁻acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “KM,Ac, decreased from 1.02–2.61 mM Ac− to 0.28–0.42 mM Ac−”
  9. Halbsättigung des Stroms Ks (Strom)K_M0,28 mM Ac⁻acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “KM,Ac, decreased from 1.02–2.61 mM Ac− to 0.28–0.42 mM Ac−”
  10. Halbsättigung des Stroms Ks (Strom)K_M0,42 mM Ac⁻acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “KM,Ac, decreased from 1.02–2.61 mM Ac− to 0.28–0.42 mM Ac−”
  11. Max. Stromdichte jmaxvmax0,0042 mmol Ac⁻ h⁻¹ cm⁻²acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “vmax,Ac and KM,Ac, decreased from 0.0042–0.0051 mmol Ac−h−1 cm−2 to 0.0031–0.0037 mmol Ac−h−1 cm−2”
  12. Max. Stromdichte jmaxvmax0,0051 mmol Ac⁻ h⁻¹ cm⁻²acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “vmax,Ac and KM,Ac, decreased from 0.0042–0.0051 mmol Ac−h−1 cm−2 to 0.0031–0.0037 mmol Ac−h−1 cm−2”
  13. Max. Stromdichte jmaxvmax0,0031 mmol Ac⁻ h⁻¹ cm⁻²acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “vmax,Ac and KM,Ac, decreased from 0.0042–0.0051 mmol Ac−h−1 cm−2 to 0.0031–0.0037 mmol Ac−h−1 cm−2”
  14. Max. Stromdichte jmaxvmax0,0037 mmol Ac⁻ h⁻¹ cm⁻²acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “vmax,Ac and KM,Ac, decreased from 0.0042–0.0051 mmol Ac−h−1 cm−2 to 0.0031–0.0037 mmol Ac−h−1 cm−2”
  15. Halbsättigung des Stroms Ks (Strom)K_M1,02 mM Ac⁻acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “KM,Ac, decreased from 1.02–2.61 mM Ac− to 0.28–0.42 mM Ac−”
  16. Halbsättigung des Stroms Ks (Strom)K_M2,61 mM Ac⁻acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “KM,Ac, decreased from 1.02–2.61 mM Ac− to 0.28–0.42 mM Ac−”
  17. Halbsättigung des Stroms Ks (Strom)K_M0,28 mM Ac⁻acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “KM,Ac, decreased from 1.02–2.61 mM Ac− to 0.28–0.42 mM Ac−”
  18. Halbsättigung des Stroms Ks (Strom)K_M0,42 mM Ac⁻acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “KM,Ac, decreased from 1.02–2.61 mM Ac− to 0.28–0.42 mM Ac−”
  19. Max. Stromdichte jmaxvmax0,0042 mmol Ac⁻ h⁻¹ cm⁻²acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “vmax,Ac and KM,Ac, decreased from 0.0042–0.0051 mmol Ac−h−1 cm−2 to 0.0031–0.0037 mmol Ac−h−1 cm−2”
  20. Max. Stromdichte jmaxvmax0,0051 mmol Ac⁻ h⁻¹ cm⁻²acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “vmax,Ac and KM,Ac, decreased from 0.0042–0.0051 mmol Ac−h−1 cm−2 to 0.0031–0.0037 mmol Ac−h−1 cm−2”
  21. Max. Stromdichte jmaxvmax0,0031 mmol Ac⁻ h⁻¹ cm⁻²acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “vmax,Ac and KM,Ac, decreased from 0.0042–0.0051 mmol Ac−h−1 cm−2 to 0.0031–0.0037 mmol Ac−h−1 cm−2”
  22. Max. Stromdichte jmaxvmax0,0037 mmol Ac⁻ h⁻¹ cm⁻²acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “vmax,Ac and KM,Ac, decreased from 0.0042–0.0051 mmol Ac−h−1 cm−2 to 0.0031–0.0037 mmol Ac−h−1 cm−2”
  23. Halbsättigung des Stroms Ks (Strom)K_M1,02 mM Ac⁻acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “KM,Ac, decreased from 1.02–2.61 mM Ac− to 0.28–0.42 mM Ac−”
  24. Halbsättigung des Stroms Ks (Strom)K_M2,61 mM Ac⁻acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “KM,Ac, decreased from 1.02–2.61 mM Ac− to 0.28–0.42 mM Ac−”
  25. Halbsättigung des Stroms Ks (Strom)K_M0,28 mM Ac⁻acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “KM,Ac, decreased from 1.02–2.61 mM Ac− to 0.28–0.42 mM Ac−”
  26. Halbsättigung des Stroms Ks (Strom)K_M0,42 mM Ac⁻acetateNicht geprüftGattungszeileKonfidenz 0,9

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “KM,Ac, decreased from 1.02–2.61 mM Ac− to 0.28–0.42 mM Ac−”
  27. Halbsättigung des Stroms Ks (Strom)Km1,02 mM Ac⁻acetateGeprüftGattungszeileKonfidenz 0,85

    Determining incremental coulombic efficiency and physiological parameters of early stage Geobacter spp. enrichment biofilms · 2020 · 10.1371/journal.pone.0234077

    “The half-saturation concentration based on acetate uptake, KM,Ac, decreases from 1st to 2nd batch cycle (from 1.02–2.61 mM Ac− to 0.28–0.42 mM Ac−) indicating an increased affinity of the maturing biofilm for acetate that results in a more effective acetate uptake.”

Prior auf Gattungsebene: Geobacter metallireducens

Ein Prior auf Gattungsebene fasst die ganze Gattung zusammen; er ist keine Messung an diesem Stamm.

Konstanten, die die Simulation antreiben

Jede Konstante stammt aus den Korpuszeilen, sonst aus dem Gattungs-Prior. Ein eingegebener Wert füllt nur eine Lücke; er überschreibt nie einen Beleg.

Lücke füllen (5)

Konstanten in diesem Lauf

Max. spezifische Wachstumsrate μmax
0,06 h⁻¹Gattungs-Prior
Halbsättigungskonstante Ks
90 mg/LGattungs-Prior
Biomasseausbeute Y
0,07 g/gGattungs-Prior
Absterbekoeffizient kd
—fehlt
Biofilmdichte
—fehlt
Max. Stromdichte jmax
7,93 A/m²DB-Zeilen
Halbsättigung des Stroms Ks (Strom)
24,8 mg/LDB-Zeilen
Halbsättigungspotenzial E_KA
—fehlt
Austauschstromdichte i₀
—fehlt
Durchtrittsfaktor α
—fehlt

Szenario – Ihre Werte, keine Belege

Acetat zu Beginn, mg/L1.000 mg/L
Dauer72 h
Anfängliche anhaftende Biomasse0,1 g/m²
Anodenfläche je Flüssigkeitsvolumen100 m²/m³
Reaktorbetrieb
Voreinstellungen aus den Belegen
  • Sättigend: S₀ = 10 × Ks = 900 mg/L.
  • Halbsättigung: S₀ = Ks = 90 mg/L.

Wachstumssimulation

Szenario: Acetat zu Beginn 1.000 mg/L · Anfängliche anhaftende Biomasse 0,1 g/m² · Anodenfläche je Flüssigkeitsvolumen 100 m²/m³ · Dauer 72 h · Satzbetrieb. Ihre Werte, keine Belege.

0,8g/m²
Maximale Biomasse
38,85h
Zeit bis 90 % Substratabbau
1,3A/m²
Maximale Stromdichte
Anhaftende Biomasseg/m²
Anhaftende Biomasse über 72 h: von 0,1 g/m² auf 0,8 g/m².00,50204060h
Acetat in der Lösungmg/L
Acetat in der Lösung über 72 h: von 1.000 mg/L auf 3,72e-9 mg/L.05001.0000204060h
StromdichteA/m²Stöchiometrische Obergrenze: 100 % coulombsche Effizienz, keine Potenzialabhängigkeit.
Stromdichte über 72 h: von 0,259 A/m² auf 9,35e-11 A/m².00,511,50204060h
  • Substratgesättigtes Wachstum
  • Verlangsamung
  • Stationär

Monod-Wachstum kennt keine Lag-Phase; die Bänder markieren, wo die Nettowachstumsrate nahe ihrem Maximum liegt, fällt, nahe null oder negativ ist.

Hinweise des Simulators
  • Kein Absterbekoeffizient: kein endogener Abbauterm, das Wachstum ist eine Obergrenze.
  • Keine Biofilmdichte: die Dicke wird nicht berechnet.
  • Substratfluss auf Acetat: der stöchiometrische Strom der Aufnahme bei 100 % coulombscher Effizienz (f_e = 0,909), ohne Potenzialabhängigkeit und ohne Erhaltungs- oder Abbauelektronen, eine Obergrenze.

Kinetik des Elektronentransfers

Zeitpunktt = 34,95 h

Verschiebt Arbeitspunkt und Umsatz; beginnt beim maximalen Strom.

Keine elektrochemischen Konstanten: der Strom ist die stöchiometrische Obergrenze der Substrataufnahme, ohne Potenzialabhängigkeit, daher gibt es keine Strom-Potenzial-Kurve.

Ein Nernst-Monod-Strom bräuchte zusätzlich Halbsättigungspotenzial E_KA.

Elektronensprünge zwischen Redoxzentren
ZELLEANODEe⁻ →

Generische Redoxzentren: für diesen Organismus sind keine Cytochrome kuratiert.

illustrativ, σ setzen für eine Rate

Dichte der Redoxzentren σ (angenommen, kein Beleg)nicht gesetzt

Diese Kurven sind eine Monod- und Nernst-Monod-Idealisierung (nach Marcus et al. 2007 und Torres et al. 2008), parametrisiert allein durch die oben aufgeführten Konstanten: jede trägt ihr n und ihre Streuung (10–90 % für Korpuswerte, ein kuratierter Bereich für den Gattungs-Prior), und eine Konstante aus einer einzigen Messung hat gar keine Streuung. Keine Diffusion im Biofilm, keine Ablösung, keine Aufteilung nach coulombscher Effizienz. Die Szenariowerte sind Ihre, keine Belege.

05 · Leistung

Leistung

Berichtete elektrochemische Leistung, die Rolle im Reaktor und was der Organismus produziert.

Elektrogen: Strong

Materialien, mit denen dieser Organismus kombiniert wird (5)

Elektrodenmaterialien, die im Materialkatalog mit diesem Organismus verknüpft sind. Ein Spitzenwert ist der beste berichtete Wert für die Kombination; die Konfidenz gibt an, wie gut die Kombination selbst belegt ist.

MaterialEingesetzt alsBiofilmSpitzenleistungmW/m²SpitzenstrommA/m²KonfidenzQuelle
Graphite brushAnodenmaterial—2.400—HochLogan et al., ES&T 2007 10.1021/es062644yHeat-treated graphite fibres (Geobacter biofilm)zugeordnet über Gattungs-Tag: Geobacter
PANI@CNT spongeAnodenmaterial—7.549—HochPANI@CNT sponge (Geobacter), 7549 mW/m² — DOI pendingPore-matched PANI shell on CNT sponge; 91.7 % coulombic efficiencyzugeordnet über Gattungs-Tag: Geobacter
Carbon clothAnodenmaterial———MittelLogan 2008 (Microbial Fuel Cells)Unmodified — surface oxidation lifts to 800 mW/m²zugeordnet über Gattungs-Tag: Geobacter
Carbon feltAnodenmaterial———MittelUnmodified baseline — see Phase C entries for activated variantszugeordnet über Gattungs-Tag: Geobacter
PDA-Fe₃O₄ / carbon feltAnodenmaterial———MittelZhang et al., Chemosphere 2024 10.1016/j.chemosphere.2024.141764Polydopamine pre-coat → in-situ Fe₃O₄ nanoparticle depositionzugeordnet über Gattungs-Tag: Geobacter

Rolle im Reaktor

Kammer: AnodeAnode: primary current producer

06 · Ökologie & Biofilm

Ökologie & Biofilm

Wie der Organismus auf einer Elektrode lebt, mit welchen Partnern er kooperiert und wo er in der Natur vorkommt.

Biofilm

  • Bildet Biofilm: ja

Bevorzugte Elektrodenmaterialien

  • Graphite
  • carbon cloth

Besiedelbare Oberfläche

Für diesen Organismus ist keine Zellbreite kuratiert, daher wird der besiedelbare Anteil gemessener Elektrodenoberfläche nicht berechnet.

Partner im Elektronenaustausch (2)

Vermittlung über leitfähige Minerale

  • Vermittelt über leitfähige Minerale: ja
  • Magnetite

Magnetite-stimulated DIET with Methanothrix harundinacea (Liu 2015).

Ökosysteme

  • Freshwater
  • Subsurface
  • Rice paddy

Isolierungsquellen

  • freshwater sediment, Potomac River, USA

07 · Anwendungen, Stammentwicklung & Sicherheit

Anwendungen, Stammentwicklung & Sicherheit

Wo der Organismus bereits eingesetzt wurde, wie gut er sich gentechnisch verändern lässt und welche Handhabung er erfordert.

Anwendungen (3)

  • Bioremediation organics
    TRL 5/9
  • Bioremediation metals
    TRL 5/9
  • Bioelectricity generation
    TRL 4/9

Stammentwicklung

Engineered strains publishedIndustrielle Relevanz 4/5

Reaktorkompatibilität

  • MFC dual chamber
  • Smfc soil
  • Sediment MFC

Genetik

  • Genetisch zugänglich: ja

qPCR-Zielgene

  • pilA
  • ppcA

Biologische Sicherheit

BSL-1
  • Pathogen: nein

Modellierungsressourcen

Verknüpftes GEM: iAF987.metallireducens

08 · Quellen & Datenqualität

Quellen & Datenqualität

Jeder Wert oben lässt sich auf eine Quelle zurückführen. So vollständig und so belastbar ist der Datensatz.

Qualität des Datensatzes

ComprehensiveKonfidenz: HighPrüfung nötigKuratiert: manual

Literaturstand 2026-04-26 · Schema v1.2.0 · aktualisiert 2026-04-28 · importiert 2026-04-28

Offene Datenlücken (2)

  • electrochemical_performance.max_current_density (audit: REQUIRED-missing for electrogen class)
  • electrochemical_performance.max_power_density (audit: REQUIRED-missing for electrogen class)

Publikationen zu diesem Organismus (29)

Publikationen der Forschungsbibliothek, deren Text diesen Organismus nennt, die neuesten zuerst. Der Hinweis zeigt die stärkste Nennung je Publikation.

  1. A Bundled Antiparallel Cytochrome Nanowire Structure Suggests Roles in Cell-Cell Electron Transfer and Biofilm Formation.
    2025 · bioRxiv : the preprint server for biologyNiedrige Konfidenz
  2. Enhancement of direct interspecies electron transfer and methane production by co-culture of dual Methanosarcina species and Geobacter metallireducens
    2025 · Frontiers in MicrobiologyNiedrige Konfidenz
  3. Microbial Methylation of Mercury in Wetlands and Its Environmental Risks
    2025 · Heavy Metals in the Environment - Contamination, Risk, and RemediationNiedrige Konfidenz
  4. Tweaking the redox properties of PpcA from <i>Geobacter metallireducens</i> with protein engineering
    2024 · Biochemical JournalNiedrige Konfidenz
  5. The varied roles of pilA-N, omcE, omcS, omcT, and omcZ in extracellular electron transfer by Geobacter sulfurreducens
    2023 · Frontiers in MicrobiologyNiedrige Konfidenz
  6. Methane production by <i>Methanothrix thermoacetophila</i> via direct interspecies electron transfer with <i>Geobacter metallireducens</i>
    2023 · mBioHohe Konfidenz
  7. Detrimental impact of the Geobacter metallireducens type VI secretion system on direct interspecies electron transfer
    2023 · Microbiology SpectrumNiedrige Konfidenz
  8. <i>RETRACTED:</i> Effect of <scp><i>Geobacter metallireducens</i></scp> nanowire on electron transfer efficiency in microbial fuel cell
    2022 · Journal of Chemical Technology &amp; BiotechnologyHohe Konfidenz
  9. Different outer membrane <i>c</i>‐type cytochromes are involved in direct interspecies electron transfer to <i>Geobacter</i> or <i>Methanosarcina</i> species
    2022 · mLifeNiedrige Konfidenz
  10. Microbe Profile: Geobacter metallireducens: a model for novel physiologies of biogeochemical and technological significance
    2022 · MicrobiologyHohe Konfidenz
  11. Effect of <i>Geobacter metallireducens</i> nanowire on electron transfer efficiency in microbial fuel cell
    2021 · bioRxiv (Cold Spring Harbor Laboratory)Hohe Konfidenz
  12. Stainless steel corrosion via direct iron-to-microbe electron transfer by <i>Geobacter</i> species
    2021 · The ISME JournalNiedrige Konfidenz

Die 12 neuesten von 29. Forschung nach diesem Organismus durchsuchen

Referenzen (2)

  1. Lovley DR, et al. (1993). Geobacter metallireducens gen. nov. sp. nov. Arch Microbiol 159:336-344.
  2. Holmes DE, et al. (2017). Metatranscriptomic evidence for DIET between Geobacter and Methanothrix in rice paddy soils. Appl Environ Microbiol 83:e00223-17.doi:10.1128/AEM.00223-17

Versionsverlauf

  1. 2026-04-27 · v1.2.0 · messai_curation
    • Added genome_metadata, isolation provenance, type-strain confirmation.
    • Added DIET conductive_mineral_mediation evidence (magnetite, Liu 2015).
    • Did NOT promote partial → comprehensive: audit flags required electrochemical_performance fields as missing. Promotion deferred until citation-supported values are added.
